UDT系列兩級永磁變頻螺桿式壓縮機技術參數:
|
型號
|
額定功率(kW)
|
工作壓力
|
容積流量(m3/min)
|
排氣出口尺寸 |
重量(KG)
|
外形尺寸
(L×W×HMM) |
|
UDT45-7VPM
|
45
|
7
|
4.1-10.2
|
Rp2
|
2280
|
2300x1300x1850(A)
|
|
UDT45-8VPM
|
8
|
4.0-10.0
|
||||
|
UDT55-7VPM
|
55
|
7
|
5.3-13.2
|
Rp2
|
2350
|
2300x1300x1850(A)
|
|
UDT55-8VPM
|
8
|
5.2-13.0
|
||||
|
UDT55-10VPM
|
10
|
4.0-10.0
|
||||
|
UDT75-7VPM
|
75
|
7
|
6.1-15.2
|
Rp2
|
2400
|
2300x1300x1850(A)
|
|
UDT75-8VPM
|
8
|
6.0-15.0
|
||||
|
UDT75-10VPM
|
10
|
4.8-12.0
|
||||
|
UDT90-7VPM
|
90
|
7
|
8.2-20.5
|
DN80
PN16 |
3750 |
3200x1850x2120(A)
3000x1850x2120(W) |
|
UDT90-8VPM
|
8
|
7.8-19.5
|
||||
|
UDT90-10VPM
|
10
|
6.4-16.0
|
||||
|
UDT110-7VPM
|
110
|
7
|
9.6-24.0
|
DN80
PN16 |
4180 |
3050x1850x2120(A)
2850x1850x2120(W) |
|
UDT110-8VPM
|
8
|
9.2-23.0
|
||||
|
UDT110-10VPM
|
10
|
7.6-19.2
|
||||
|
UDT132-7VPM
|
132
|
7
|
11.8-29.5
|
DN80
PN16 |
4280
4080 |
3050x1850x2120(A)
2850x1850x2120(W) |
|
UDT132-8VPM
|
8
|
10.8-27.0
|
||||
|
UDT132-10VPM
|
10
|
9.2-23.0
|
||||
|
UDT160-7VPM
|
160
|
7
|
13.6-34.0
|
DN80
PN16 |
4400
4200 |
3050x1850x2120(A)
2850x1850x2120(W) |
|
UDT160-8VPM
|
8
|
13.2-33.0
|
||||
|
UDT160-10VPM
|
10
|
10.8-27.0
|
||||
|
UDT185-7VPM
|
185
|
7
|
15.6-39.0
|
DN100
PN16 |
5900
5600 |
3600x1850x2150(A)
3050x1850x2150(W) |
|
UDT185-8VPM
|
8
|
15.4-38.5
|
||||
|
UDT185-10VPM
|
10
|
13.0-32.5
|
DN100
PN16 |
5100
4000 |
3050x1850x2120(A)
2850x1850x2120(W) |
|
|
UDT200-7VPM
|
200
|
7
|
17.4-43.5
|
DN125
PN16 |
8000
7600 |
4200x2150x2250(A)
3400x2150x2250(W) |
|
UDT200-8VPM
|
8
|
16.4-41.0
|
||||
|
UDT200-10VPM
|
10
|
14.6-36.5
|
DN100
PN16 |
5900
5800 |
3900x1850x2150(A)
3350x1850x2150(W) |
|
|
UDT220-7VPM
|
220
|
7
|
20.0-50.0
|
DN125
PN16 |
8100 |
4200x2150x2250(A)
3400x2150x2250(W) |
|
UDT220-8VPM
|
8
|
18.5-46.0
|
||||
|
UDT220-10VPM
|
10
|
16.4-41.0
|
||||
|
UDT250-7VPM
|
250
|
7
|
21.2-53.0
|
DN125
PN16 |
8200 |
4200x2150x2250(A)
3400x2150x2250(W) |
|
UDT250-8VPM
|
8
|
20.0-50.0
|
||||
|
UDT250-10VPM
|
10
|
18.4-46.0
|
||||
|
UDT280-7VPM
|
280
|
7
|
23.6-59.0
|
DN125
PN16 |
8300 |
4200x2150x2250(A)
3400x2150x2250(W) |
|
UDT280-8VPM
|
8
|
22.4-56.0
|
||||
|
UDT280-10VPM
|
10
|
20.0-50.0
|
||||
|
UDT315-7VPM
|
315
|
7
|
26.0-65.0
|
DN125
PN16 |
10500
10000 |
5000x2150x2300(A)
3850x2150x2300(W) |
|
UDT315-8VPM
|
8
|
24.4-61.0
|
||||
|
UDT315-10VPM
|
10
|
21.2-53.0
|
UDT節能永磁變頻低壓兩級壓縮技術參數:
|
型號
|
額定功率(kW)
|
工作壓力
|
容積流量(m3/min)
|
排氣出口尺寸 |
重量(KG)
|
外形尺寸
(L×W×HMM) |
|
UDT75-5VPM
|
75
|
5
|
7.7-19.2
|
Rp3
|
3200
|
2900x1560x1870(A)
|
|
UDT90-5VPM
|
90
|
5
|
9.0-22.5
|
DN80
PN16 |
3800 |
3050x1850x2120(A)
2850x1850x2120(W) |
|
UDT110-5VPM
|
110
|
5
|
11.0-27.5
|
DN125
PN16 |
4230 |
3200x2050x2120(A)
3000x1850x2120(W) |
|
UDT132-5VPM
|
132
|
5
|
13.0-32.5
|
DN125
PN16 |
4300 |
3200x2050x2120(A)
3000x1850x2120(W) |
|
UDT160-5VPM
|
132
|
5
|
16.4-41.0
|
DN125
PN16 |
6500 |
3850x2150x2150(A)
3400x2150x2250(W) |
|
UDT200-5VPM
|
200
|
5
|
20.0-50.0
|
DN150
PN16 |
8160 |
4200x2150x2250(A)
3400x2150x2250(W) |
|
UDT220-5VPM
|
220
|
5
|
22.4-56.0
|
DN150
PN16 |
8160 |
4200x2150x2250(A)
3400x2150x2250(W) |
|
UDT250-5VPM
|
250
|
5
|
23.6-59.0
|
DN150
PN16 |
8200 |
4200x2150x2250(A)
3400x2150x2250(W) |
|
UDT90-4.5VPM
|
90
|
4.5
|
9.0-22.5
|
DN80
PN16 |
3800 |
3050x1850x2120(A)
2850x1850x2120(W) |
|
UDT110-4.5VPM
|
110
|
4.5
|
11.2-28.0
|
DN125
PN16 |
4230 |
3200x2050x2120(A)
3000x1850x2120(W) |
|
UDT132-4.5VPM
|
132
|
4.5
|
13.6-34.0
|
DN125
PN16 |
4300 |
3200x2050x2120(A)
3000x1850x2120(W) |
|
UDT185-4.5VPM
|
180
|
4.5
|
20.0-50.0
|
DN125
PN16 |
8000 |
4200x2150x2250(A)
3400x2150x2120(W) |
|
UDT200-4.5VPM
|
200
|
4.5
|
21.2-53.0
|
DN150
PN16 |
8160 |
4200x2150x2250(A)
3400x2150x2120(W) |
|
UDT220-4.5VPM
|
220
|
4.5
|
23.6-59.0
|
DN150
PN16 |
8200 |
4200x2150x2250(A)
3400x2150x2120(W) |
